TX-SR402/8240/HT-R420
SPECIFICATIONS-1
TX-SR402/TX-SR8240
Audio Outputs
Analog Outputs: TAPE, VIDEO1
Subwoofer Pre Outputs: 1
Speaker Outputs: 5+2
Phones: 1
Specifications and features are subject to change without notice.
Power Supply: AC 220-230 V, 50/60 Hz
Power Consumption: 300W
Dimensions: 435 W x 150 H x 374 D mm
17 1/8 W x 5 7/8 H x 14 3/4 D inches
Weight: 8.8 kg
18.4 lbs
Video Inputs
S-Video Compatible Jack Input: DVD, VIDEO1, VIDEO2
A/V Input: DVD, VIDEO1, VIDEO2, VIDEO3
Video Outputs
S-Video Compatible Jack Output: MONITOR, VIDEO1
A/V Output: MONITOR, VIDEO1
Audio Inputs
Digital Inputs: 1 (Optical ) , 1 (Coaxial )
Analog Inputs: DVD (MULTI CHANNEL), CD, TAPE,
VIDEO1, VIDEO2, VIDEO3
Multichannel Inputs: 6
General
Power Output:
All channels: 100 W (6 , 1kHz, JEITA)
Dynamic Power: 160 W + 160 W (3 , Front)
125 W + 125 W (4 , Front)
85 W + 85 W (8 , Front)
THD
(Total Harmonic Distortion): 0.08 % (Power Rated)
Damping Factor: 60 (Front, 1kHz, 8 )
Input Sensitivity and Impedance: 200 mV/ 47 k (LINE)
Output Level and Impedance: 200 mV/ 470 (REC OUT)
Frequency Response: 10 Hz~100 kHz / +1 dB -3 dB (Direct
mode)
Tone Control: +12 dB, -12 dB, 50 Hz (BASS)
+12 dB, -12 dB, 20k Hz (TREBLE)
SN Ratio: 100 dB (CD, IHF-A)
Speaker Impedance: 6-16
Amplifier Section
Input Sensitivity/Output Level and Impedance:
1 Vp-p /75 (Component and S-Video Y)
0.28 Vp-p /75 (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 (S-Video C)
1 Vp-p /75 (Composite)
Video Section
FM
Tuning Frequency Range: 87.5 MHz~108.0 MHz
Usable Sensitivity: Stereo 17.2 dBf 2 V (75 IHF)
Mono 11.2 dBf 1 V (75 IHF)
S/N Ratio: Stereo 70 dB (IHF-A)
Mono 76 dB (IHF-A)
THD: Stereo 0.3 % (1kHz)
Mono 0.2 % (1kHz)
Frequency Response: 30 Hz~15 kHz / +1 dB, -1 dB
Stereo Separation: 45 dB ( 1kHz )
AM
Tuning Frequency Range: 522-1611 kHz
Usable Sensitivity: 30 V
S/N Ratio: 40 dB
THD: 0.70%
Tuner Section
