Onkyo TX-SR403

1/62 PAGE
TX-SR403/8340
<Notes>
(S) : Silver model only
(B) : Black model only
<403GR>: TX-SR403 Chinese model only
<8340GR>: TX-SR8340 Chinese model only
EXPLODED VIEW PARTS LIST
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EV
A001 RETAINER (F) 1 27141972
EV
A002 SCREW 3TTB+10B(BC) 13 838430108
EV
A003 SCREW 3TTB+8B(BC) 37 838430088
EV
A004 SCREW 3TTB+8B(CU)SR 20 801618
EV
A010 CHASSIS --- 1 27100460A
EV
A011 TAPE TAPE(CLOTH-16U) (1) 29110083
EV
A013 WIRE TIE BSK-1 6 260208
EV
A014 CLIP CS-1U 2 27255004
EV
A015 HOLDER KGLS-14RT 3 27190524
EV
A016 HOLDER HOLDER 2 27190991
EV
A023 SCREW 4TTC+8C(BC) 4 830440089
EV
A025 TAPE TAPE(CLOTH-16U) (1) 29110083
EV
A028 BUSHING S-RELIEF #2271 1 27300750 !
EV
A030 HEAT SINK AS. 1 27160563B
EV
A037 SCREW 3SMS8W.SW+14B(BC) 12 801433
EV
A040 BRACKET (U) 1 27130986
EV
A045 SHLD PLT (R) 1 27150504
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
