Onkyo TX-SR403

6/62 PAGE
EV
U04 HEADPHONE JACK PC board ass'y NAETC-8516-1D 1 1B068516-1D
EV
U05 AMPLIFIER PC board ass'y NAAF-8523-1D 1 1B068523-1D
EV
U06 SEC. TERMINAL-2 PC board ass'y NAPS-8524-1D 1 1B068524-1D
EV
U08 THERMAL SENSOR PC board ass'y NAETC-8526-1D 1 1B068526-1D
EV
U09 HOLDER PC board ass'y NAETC-8527-1D 1 1B068527-1D
EV
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1D 1 1B068544-1D
EV
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1D 1 1B068546-1D
EV
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1D 1 1B068547-1D
EV
U15 SPEAKER TERMINAL PC board ass'y NAETC-8548-1D 1 1B068548-1D
EV
U16 VIDEO PC board ass'y NAVD-8549-1D 1 1B068549-1D
EV
U17 DRIVER AMPLIFIER PC board ass'y NAAF-8550-1D 1 1B068550-1D
EV
U18 TUNER UNIT TFCE1E512A 1 240135
TX-SR403/8340
PC BOARD PARTS LIST
U01 DISPLAY PC BOARD (NADIS-8513-1D)
U02 DSP PC BOARD (NADG-8514-1D)
U03 SWITCH PC BOARD (NASW-8515-1D)
U04 HEADPHONE JACK PC BOARD (NAETC-8516-1D)
CIRCUIT NO.
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB1
U131 PHT CP GP1FAV51RKF5 1 24120129
PCB1
U821 REMO SENS GP1UM281XKVFH=16MM 1 241361
PCB1
Q801 FL TUBE 16BT127GNK 1 213028
PCB1
Q801A HOLDER (FL) 1 27191222B
PCB1
Q131 IC 74HCU04F 1 222740046R2
PCB1
Q151 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q151 or IC SN74AHC541PWR ( 1) 22274541IR2TI
PCB1
Q152 IC TC74HCT7007AF 1 222740077R2TO
PCB1
Q171 IC TC7WU04FU 1 22240935R2
PCB1
Q201 IC CS494003CQZ 1 22242039R3
