Device Specifications
Processor • Dual-core ARM Cortex A9 CPU
Modem • Quectel EG95-NAXD Cat-4 LTE
LTE Band Support • B2/B4/B5/B12/B13/B25/B26
LTE Data Rates • Up to 150 Mbps down and 50 Mbps up
Antennas
• Two Wideband 5G/4G Terminal Mount Antennas
• Hinged 90° termination with SMA(M) Connector
SIM Cards • Dual micro-SIM support
Ethernet
• One RJ-45 10/100/1000 Ethernet WAN port
• One RJ-45 10/100/1000 Ethernet LAN port
FXS Ports • Four RJ-11 analog FXS ports
Telephony • 55Vrms Low Power Ringing
Power Adapter • AC-DC Adapter w/ MicroFit+ connector
Power Input • 100-240 VAC 50-60Hz
Power Output • 12VDC/3A 36W
Battery Backup
• Replaceable battery pack 3S3P Li-ion battery: 10.95V, 3A
• Capacity 85.4 Wh (7.8 Ah) provides > 8 hours of standby time
Display • 320x240 LCD display
Switches
• Master On/Off
• Factory reset (recessed)
Dimensions • W 30cm x H 6cm x D 20cm when sitting horizontally
Operating Temperature • 0 – 40° C
Warranty • 1-Year Limited Warranty
