21 OPAL-RT Technologies OP5600/OP5650 User Manual
OP5600 Series/OP5650 Simulator
Flat Carrier Specifications
SPECIFICATIONS
Product name OP5650 V3
Power supply Universal input and active power factor correction 650W continuous power
DC to DC converters for analog voltage
Power rating Input : 100-240VAC, 50-60Hz, 10A/5A
Power: 600W
Input/output power -30V to +30V maximum
I/O connectors 4 panels of 4 DB37F connectors
4 rear SFP ports
Monitoring connectors 4 panels of RJ45 connectors
Fiber optic synchronization connectors (Tx/Rx)
PC interface Standard PC connectors (monitor, keyboard, mouse and network)
PCI slots 3 PCIe slots (capable of accommodating up to 2 PCI boards)
Hard disk 512 Gb, 7200 rpm, SATA
Dimensions 48.3 x 45.7 x 17.8cm (19” x 18” x 7”)
Weight With PC: 9.07 - 15 Kg (20 lbs to 33 lbs)
Without PC: 4.54 - 5.9 Kg (10 lbs to 13 lbs)
Operating temperature 10 to 35 ºC (50 to 95ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Maximum rated ambient temperature 40Cº (104ºF)
Relative humidity 10 to 90% non-condensing
Maximum altitude 2000 m (6562 ft.)
FLAT CARRIER SPECIFICATIONS
Part Number 126-0591
Number of mezzanines 8 with Artix 7 configuration
Dimensions 38.1 x 38.1 cm (15 in x 15 in)
I/O connector 8 connectors, 160 positions each
Output power supply
(from DC-to-DC converters)
±12 VDC @ 1.2 A (4 mezzanine A)
±12 VDC @ 1.2 A (4 mezzanine B)
±18 VDC @ 800 mA (4 mezzanine A)
±18 VDC @ 800 mA (4 mezzanine B)
Input power supply +12 VDC @ 6 A
+5 VDC @ 3A
Operating temperature 10 to 40 ºC (50 to 104ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Relative humidity 10 to 90%, non condensing
Maximum altitude 2,000 m (6562 ft.)
