Open Date EUROCODE 300 - Digi50 Connections and Options

Eurocode Digi50 Controller V1.03 04/07/2005 Page - 18 -
Digi50 Connections shown from rear of the Control Unit
Air Switch
Print Relay
COM
HEATER HEATER
RELAY
NC
NO
T
FAULT
A
SWITCH
AIR
B
PMT F1
PRINT
N/C
RELAY
COM
N/O
P+
E
24VDC
S-D1F2 D2 S+ P-
LN
G5V-1
OMRON
TRK 293709 Issue 4
(Screen connected to Earth)
Grey twin Screened Cable.
Trigger (Print Signal)
Black (-)
Red (+)
to 9 pin "D" plug.
Multicore cable
Black Twin Core Cable.
Solenod Valve
White Printmaster Only
Green
Yellow
Mauve
Brown (-)
Black O/P
Pink (+)
Thermistor
Door Switch
Foil Sensor
(if fitted)
Blue (-)
Red (+)
Blue
Red
Heater
240V AC
Fault Relay
(Three Core White)
Mains Cable
On/Off Switch
(Screen connected to Earth)
To Chassis (Earth Stud)
