Open Date EUROCODE 300 - Page 19

Eurocode Digi50 Controller V1.03 04/07/2005 Page - 19 -
Connection Details - Row “c”
Trigger/Print Signal
- Grey twin core screened
.
See page 39 for details of “Input Print Signals”
P+. Red External trigger input. + volts connection.
P-. Black External trigger input. – volts connection.
Solenoid Valve
- Black twin core.
S+ Red Solenoid output. + volts connection.
S-. Blue Solenoid output. – volts connection.
Printer
– Multi-Core screened to 9 pin D plug. D plug Connections.
D2. Mauve Type Holder door safety switch return. Pin 6
D1. Brown Feed to the safety switch & foil sensor, –0v DC. Pin 5
F2. Pink Feed to the foil sensor, +14v DC. Pin 9
F1. Black Output from the foil sensor. Pin 8
PM. White Foil sensor
Printmaster only.
Pin 7
T. Green Thermistor connection. Pin 2
T. Yellow Thermistor connection. Pin 1
H. Red Heater element. Pin 3
H. Blue Neutral ac heater element. Pin 4
Mains Cable
- Three core white.
N. Blue Neutral.
L. Brown Live.
E. Yellow/Green Earth.
