Opt PD3000-RGB - INTRODUCTIONS of FB4 INTEGRATED DEVICES

1
2
3
4
5
6
7
8
9
10 SD-Card Slot
Safety Ring
Safety element; current rang dffers for different SERIES of the show systems
The ring for enwinding a safety rope when the laser device will be installed
on out-of-reach locaons.
FB4 Area
LAN 1 & LAN 2
ILDA OUT at FB4
INTERLOCK Connecons
PowerCON in & out
FUSE
Power Switch
Keyhole
Signal comes frrom FB4
Laser output is available only when the interlock is connected.
Both posions can be used to connect a laser emergency switch(E-stop box).
Sub-DB25 connecon, signal comes from FB4. Directly wired to FB4 board
thus this ILDA output can be used to daisy chain the other laser projectors
which are not FB4 integrated
Power connecons input and output
Power On/Off
Key Switch, laser output is available when the key is moved to posion “on”
Memory card slot on FB4 controller
FB4 controller’s interface is integrated with featured funcons, seng area.
INTRODUCTIONS of FB4 INTEGRATED DEVICES
