Optibelt ZRP - Page 18

17
deunitnoc,01TnoitceSmm5hctip–D5TnoitceSmm01hctip–D01TnoitceS
.oNtleB
hctiP
)mm(
.oN
hteetfo.oNtleB
hctiP
)mm(
.oN
hteetfo.oNtleB
hctiP
)mm(
.oN
hteetfo
Standard widths b
St
(mm):
10, 12, 16, 20, 25, 32, 50
Standard widths b
St
(mm):
6, 8, 10, 12, 16, 20, 25
Standard widths b
St
(mm):
10, 12, 16, 20, 25, 32, 50
Section Pitch Tooth Overall Tooth Tooth
depth belt width angle
thickness
th
t
h
s1
s2 β
(mm) (mm) (mm) (mm) (°)
T5D 5.0 1.20 3.40 2.65 40
T10D 10.0 2.50 7.00 5.30 40
3.2 ZRM/ZRP timing belt range
optibelt ZRM double section timing belts, metric sizes
Further sizes on request. * Non stock
Table 3.2 continued
L
wSt
z
R
L
wSt
z
R
z
R
L
wSt
T10/1150 1150.0 115
T10/1200 1200.0 120
T10/1210 1210.0 121
T10/1240 1240.0 124
T10/1250 1250.0 125
T10/1300 1300.0 130
T10/1320 1320.0 132
T10/1350 1350.0 135
T10/1390 1390.0 139
T10/1400 1400.0 140
T10/1420 1420.0 142
T10/1440 1440.0 144
T10/1450 1450.0 145
T10/1460 1460.0 146
T10/1500 1500.0 150
T10/1560 1560.0 156
T10/1600 1600.0 160
T10/1610 1610.0 161
T10/1700 1700.0 170
T10/1750 1750.0 175
T10/1780 1780.0 178
T10/1800* 1800.0 180
T10/1880 1880.0 188
T10/1960 1960.0 196
T10/2250 2250.0 225
T5/ 300 D* 300.0 60
T5/ 350 D* 350.0 70
T5/ 400 D* 400.0 80
T5/ 410 D 410.0 82
T5/ 450 D* 450.0 90
T5/ 460 D 460.0 92
T5/ 480 D 480.0 96
T5/ 500 D 500.0 100
T5/ 515 D 515.0 103
T5/ 550 D 550.0 110
T5/ 590 D 590.0 118
T5/ 600 D* 600.0 120
T5/ 620 D 620.0 124
T5/ 650 D 650.0 130
T5/ 700 D 700.0 140
T5/ 750 D 750.0 150
T5/ 800 D 800.0 160
T5/ 815 D 815.0 163
T5/ 850 D* 850.0 170
T5/ 860 D 860.0 172
T5/ 900 D 900.0 180
T5/ 940 D 940.0 188
T5/1100 D 1100.0 220
T10/ 260 D 260.0 26
T10/ 530 D 530.0 53
T10/ 600 D 600.0 60
T10/ 630 D 630.0 63
T10/ 660 D 660.0 66
T10/ 700 D 700.0 70
T10/ 720 D 720.0 72
T10/ 750 D 750.0 75
T10/ 800 D 800.0 80
T10/ 840 D 840.0 84
T10/ 900 D 900.0 90
T10/ 980 D 980.0 98
T10/1000 D* 1000.0 100
T10/1100 D 1100.0 110
T10/1200 D* 1200.0 120
T10/1210 D 1210.0 121
T10/1240 D 1240.0 124
T10/1250 D 1250.0 125
T10/1300 D* 1300.0 130
T10/1320 D 1320.0 132
T10/1350 D 1350.0 135
T10/1400 D 1400.0 140
T10/1420 D 1420.0 142
T10/1500 D 1500.0 150
T10/1600 D* 1600.0 160
T10/1610 D 1610.0 161
T10/1700 D 1700.0 170
T10/1800 D 1800.0 180
T10/1880 D 1880.0 188
Order example for ZRM D: 50 T 10/1420 D
Width (mm)
Section
Pitch length (mm)
Double section timing belts
T20 and AT sizes
on request
Construction:
polyurethane with steel tension cord
•
•
•
••
•• •
•
•
•
•
•
•
•
