BIOLINE Manual for installation and use
OPTIKON 2000
Acoustic Output Parameters
according to IEC/EN/DIN 61157
Manufacturer: Optikon 2000 SpA
Device: Bioline (ref.141002)
Transducer: Biometry probe, 10 MHz (ref.143001)
Parameter Unit Mode A
Maximum Power [mW] 0.003 ± 0.001
Peak negative acoustic pressure [p
-
] [MPa] 1.3 ± 0.14
Output beam intensity [I
OB
] [mW/cm²] 0.006 ± 0.001
Spatial peak temporal average intensity [I
SPTA
] [mW/cm²] 0.2 ± 0.04
Focal length [l
p
] [mm] 22.6
Pulse beam width (6 dB, parallel) [w
pb6
║] [mm] 0.75
Pulse beam width (6 dB, orthogonal )[w
pb6
┴] [mm] 0.82
Pulse repetition rate [prr] Hz 20
Scan repetition rate [srr] Hz ---
[mm] 3.1
Output Beam Dimensions
[mm] 3.4
Arithmetic-mean acoustic working frequency [f
awf
] [MHz] 10.8
Transducer to transducer output face distance [l
tt
] [mm] ---
Transducer standoff distance [l
ts
] [mm] Contact
Power up fraction 100 %
Acoustical initialization fraction 100 %
Power up mode Default
Initialization mode Default
Freeze output Yes
Modes included ---
Control settings ---
Code 141002EN 5-4 26.10.05 Rev.0
