Optoma DC450 - Connecting External Devices; Connecting to TVs and Projectors via VGA

12
Step 2 / Connecting with Components
Product
Port
Cable
Display
Device Port
PC Port
VGA
RGB OUTPUT RGB INPUT
RGB INPUT RGB OUTPUT
HDMI
Mini HD
OUT
HDMI-INPUT
Mini HD
IN
HDMI-
OUTPUT
USB
TYPE B Port
TYPE A Port TYPE A Port
▶Standard TV and Projector
• Connect via VGA OUTPUT
To display images, you can use VGA cable to connect to your television’s RGB port via
the VGA OUT connector.
RGB
