Optoma EP719 Service Manual

1-4
EP719 / EP716 / EP719R / EP716R /
EP719P / EP716P
- “Power” Green
On-Screen Display Menu- 11 languages selection
English, French, German, Italian, Spanish, Norwegian, Russian,
Traditional Chinese, Simplified Chinese, Japanese, Korea
Audio - One 8 ohm 2W speaker
Panel Spec (EP719) - TI DMD,0.55” 12 degree DDR XGA Digital Mirror Device
- Number of active dots : 1024(H) x 768(V)
Projection Lens - F# 2.7 - 3.0@2.4m, f=21.83~23.81mm @2.36m.
1.10 x Manual Zoom Lens
Projection Image Size - Adjustable from 34.67” to 254.22” (Diagonal)
Throw Distance - Suggested throw distance: 1.5~10m (Optical Performance)
1.5~12m(Mechanical travel)
Brightness (EP719) - 1530 ANSI Lumens (Typical)
- 1200 ANSI Lumens (Minimum)
Brightness (EP716) - 1300 ANSI Lumens (Typical)
- 1000 ANSI Lumens (Minimum)
Contrast - 1500:1 Typical (Full on / full off)
- 1000:1 Minimum (Full on / full off)
Uniformity - 85% Marketing (Japan standard)
- 75% Typical (Japan standard)
- 60% Minmum (Japan standard)

Optoma EP719 Specifications

Power

power supply voltage	100-240V
power consumption (max)	265 Watts
power consumption (standby)	<15 Watts

Operating Environment

operating temperature	5 - 35ºC
operating humidity	80%
noise level (STD/ECO)	32dB/28dB

Display

native resolution	1024 x 768
maximum resolution	1400 x 1050
contrast ratio	2500:1

Projection

projection distance	1.2 to 10 m
throw ratio	1.93 - 2.13:1
projection lens	F=2.7-3.0, f=21.83-23.81 mm

Weight and Dimensions

weight	2.0 kg
dimensions	230 x 95 x 210 mm
image size (diagonal)	0.6 to 7.62 m
