Optoma EP719 Service Manual

1-5
EP719 / EP716 / EP719R / EP716R /
EP719P / EP716P
1-2 Compatible Modes(Analog & Digital)
EP719 Analog
Compatibility Resolution V-Sync[Hz] H-Sync[KHz]
VGA 640x350 70 31.5
640x350 85 37.9
640x400 85 37.9
640x480 60 31.5
640x480 72 37.9
640x480 75 37.5
640x480 85 43.3
720x400 70 31.5
720x400 85 37.9
SVGA 800x600 56 35.2
800x600 60 37.9
800x600 72 48.1
800x600 75 46.9
800x600 85 53.7
XGA 1024x768 60 48.4
1024x768 70 56.5
1024x768 75 60.0
1024x768 85 68.7
SXGA 1152x864 70 63.8
1152x864 75 67.5
1152x864 85 77.1
1280x1024 60 63.98
1280x1024 75 79.98
SXGA+ 1400x1050 60 63.98
MAC LC13" 640x480 66.66 34.98
MAC II 13" 640x480 66.68 35
MAC 16" 832x624 74.55 49.725
MAC 19" 1024x768 75 60.24
MAC 1152x870 75.06 68.68
MACG4 640x480 60 31.35
i Mac DV 1024x768 75 60
i Mac DV 1152x870 75 68.49
i Mac DV 1280x960 60 60

Optoma EP719 Specifications

Power

power supply voltage	100-240V
power consumption (max)	265 Watts
power consumption (standby)	<15 Watts

Operating Environment

operating temperature	5 - 35ºC
operating humidity	80%
noise level (STD/ECO)	32dB/28dB

Display

native resolution	1024 x 768
maximum resolution	1400 x 1050
contrast ratio	2500:1

Projection

projection distance	1.2 to 10 m
throw ratio	1.93 - 2.13:1
projection lens	F=2.7-3.0, f=21.83-23.81 mm

Weight and Dimensions

weight	2.0 kg
dimensions	230 x 95 x 210 mm
image size (diagonal)	0.6 to 7.62 m
