EW536/HD66/DW318
Condential
IV
Disassemble Speaker 2-15
Rod Adjustment 2-16
Re-write Lamp Usage Hour 2-17
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC MODE 4-4
Video Performance 4-8
Optical Performance Measure 4-10
Others 4-12
Chapter 5 Firmware Upgrade
Section 1: System Firmware Upgrade 5-1
Equipment Needed 5-1
DLP Composer Lite Setup Procedure 5-2
Firmware Upgrade Procedure 5-4
Section 2: 8051 Firmware Upgrade Procedure 5-8
Equipment Needed 5-8
NLINK Setup Procedure 5-9
USB Driver Upgrade Procedure 5-11
