EW536/HD66/DW318
Condential
II
Item P/N Description Parts Supply
1 70.8FF05G001 ASSY TOP COVER MODULE EW536
2 70.8FF15G001 ASSY BOTTOM MODULE EW536
3 70.8FF09G001 ASSY ONE FAN MODULE EW536
SP.8EH01GC01 LAMP MODULE FOR PROJECTOR ES526/EX536 V
4 70.8EH05G001 ASSY LAMP MODULE ES526
5 51.8CS11G001
LAMP DRIVER HOLDER PPS BLACK PDG-
DSU30
6 70.8FF02G001 ASSY ENGINE MODULE EW536
7 85.0A123G050 SCREW P/F MECH M3*5 Ni
70.8FF16GR01
ASSY IO COVER MODULE FOR
EW536(SERVICE)
V
8 35.8FF01G001 LABEL FOR IO COVER EW536
9 85.1A323G080 SCREW PAN MECH M3*8 BLACK “GREEN”
10 41.89Z02G001 HDMI CONNECTOR GASKET L15*W10*H1
11 85.005AGG308 SCREW HEX I/O #4-40 H3.5*L8 NI NYLOK
12 42.00454G001 W.A 8P 120mm MB TO LVPS X1160
13 51.00001G001 CABLE TIE PG-YJ-80
14 51.8CS03G012
FRONT COVER FOR IR PC MN3600H BLACK
ES526
15 70.8FF01G001 ASSY IO COVER MODULE EW536
16 51.8FF01G001 MYLAR FOR MB SHIELDING EW536
70.8EH17GR01
ASSY LAMP COVER MODULE FOR
ES526(SERVICE)
V
17 51.8CS05G001 LAMP COVER PC MN3600H BLACK PDG-DSU30
18 52.8CS05G002 MB SHIELDING AIR THIGHT JK-1105 PDG-DSU30
19 85.1A526G060 SCREW PAN MECH M2.6*6 Ni NYLOK
20 61.8CS05G021 MAIN BD SHIELDING SECC 0.6T EW536
21 61.8CS04G001 TOP SHIELDING SECC 0.4T PDG-DSU30
22 61.00018G003
LOCK SCREW PAN MECH M3*8.5-3.5
BLACK(1018+HEAT TREATMENT)
23 80.8FF01G001 PCBA MAIN BD FOR EW536 V
24 85.1A123G060 SCREW PAN MECH M3*6 NI
25 51.8CS19G001 COLOR WHEEL MYLAR PDG-DSU30
70.8EH16GR01
ASSY PHILIPS LAMPDRIVER MODULE 185W
FOR EW536(SERVICE)
V
26 75.8BF03G011
ASSY PHILIPS LAMPDRIVER 185W (for MOS
LVPS)
27 80.88N05G001 PCBA IR BOARD FOR EP721 V
