EW536/HD66/DW318
ASSY COLOR WHEEL MODULE Z15
Item P/N Description Parts Supply
70.8FG23GR01
ASSY COLOR WHEEL MODULE 1510X (SERV-
ICE)
V
1 61.8CP03G001 CW BRACKET SECC X1161
2 80.8EG04G002 PCBA PHOTO SENSOR BOARD FOR HD20 V
3 23.8BA19G001
YO 6S HE3 CW R81Y41G84C31W52B71, URD20
MOTOR
4 85.1A126G040 SCREW PAN MECH M2.6*4 Ni
5 51.82Y29G001
TAPE 3M J350 10*5mm FOR COLOR WHEEL
DP715
6 52.83615G011 COLOR WHEEL DISC RUBBER, EzPro755
7 61.83628G001 COLOR WHEEL SHOULDER SCREW
