EX762/EW762
Condential X
Item P/N Description Parts Supply
1 23.8EF01G002
PROJECTION LENS YM25 WITH BLACK PAINT-
ING INSIDE
2 70.8FB15G001 ASSY RELAY MODULE EX762
70.8FB22GR01
ASSY OPTICAL ENGINE MODULE
EX762(SERVICE)
V
3 23.8AH20G011 YO CONDENSER 1 FOR A15W
4 85.1A526G060 SCREW PAN MECH M2.6*6 Ni NYLOK
5 80.8EF02G001 PCBA DMD BD FOR X15-II XGA V
70.8EF42GR01 ASSY ROD MODULE EX615 (SERVICE) V
6 70.8EF36G001 ASSY ROD MODULE EX615
7 70.8FB17G001 ASSY ENGINE BOTTOM MODULE EX762
8 48.8CQ01G003
0.55” XGA 2xLVDS SERIES 450 DMD -8 1076-
603cB TI
V
9 52.8CP01G011 DMD RUBBER EX615
10 52.8CP02G001 DMD BOARD RUBBER X1161
11 85.4A826G118
STEP SCREW FOR TYPEX DMD M2.6*11.8mm,
X15
12 52.8CP04G001
S450 0.55” XGA/SVGA DMD thermal pad, FUJIPO-
LY, Sarcon XR-HE, 18.4x12.5x0.5 mm
13 70.8CP11G001 ASSY ENGINE BASE Z15
14 61.8FB03G001 DMD HEATSINK AL6063 280W EX762
15 70.8FB19G001 ASSY COLOR WHEEL MODULE EX762
16 61.8EF03G001 CONDENSER LIGHT STOP EX615
17 23.8AH20G012 YO CONDENSER 2 FOR A15W
18 61.88N13G002 ROD COVER NEW SUS301 X15
19 61.88N12G001 ROD SPRING SUS301,X15
20 85.WA321G040 SCREW PAN TAP M1.7*4 BLACK
21 85.00823G080 HEX SCREW M3*H8*L5.3,BRASS
22 41.83F16G001 GASKET/W*10 H*10 L*40
23 41.85H14G001 EMI TAPE W40*L50 ALU
24 61.8EF01G001 DMD MASK EX615
