Optoma EX762 - Page 92

EX762/EW762
Condential XI
Condential
ASSY COLOR WHEEL MODULE
Item P/N Description Parts Supply
70.8FB23GR01
ASSY COLOR WHEEL MODULE EX762 (SERV-
ICE)
V
1 61.8CP03G001 CW BRACKET SECC X1161
2 80.8EF04G001 PCBA PHOTO SENSOR BOARD FOR EX615 V
3 23.8FB19G001
YO 5S R76Y32G78W98B76 CW_URD20 MOTOR_
TIM CHANGED TO W/B IN B
4 85.1A126G040 SCREW PAN MECH M2.6*4 Ni
5 51.8FB08G001 3M TAPE 9x45x0.08t mm EX762
6 52.83615G001 COLOR WHEEL DISC RUBBER, EzPro755
7 61.83628G001 COLOR WHEEL SHOULDER SCREW,EzPro755
