Review the Main Board Connector
Remove the Connectors. Remove the Connectors.
Remove the Connectors. Remove the Connectors.
D
I
S
A
SS
E
M
B
L
Y
Remove the Connector.
CN2 (RJ45)
CN452 (Keypad)
CN802 (Engine Fan)
CN451 (Front IR)
CN650 (C/W)
CN850 (Index)
CN530 (Ballast)
CN852 (Thermal Breaker)
CN800 (Blower Fan1)
CN801 (Lamp Fan2)
CN903 (IO CONN)
CN905 (Power Fan3)
CN900 (Power Supply)
