or
1
1
2
1
2
3
: When all adjustments are done, the wall plate covers can be used to cover the blank
area on the top of wall plate. The number of wall plate cover used depends on the size of
blank area. But the wall cover must be used in an specific order as the picture on left shows.
A
B
A
B
Screen Adjustment Direction
Step 8: Adjusting the horizontal roll
A
B
A
B
Horizontal Roll Knob
Screen Adjustment Direction
Step 9: Adjusting the horizontal rotation
Horizontal Rotation Knob
Step 10: Using the decorative covers
Finally, put the wall cover on.
Product Information
6
Net Weight
Weight Capacity
Extendable Length
Adjustment Angle
5.0kg(11lb)
15.0kg(33lb)
325mm-740mm(12.8-29in)
±
5°
Verticaltilt, Horizontal roll, Horizontal rotation
A
B
A
B
Note
1
2
3
4
Wall plate covers
