English
15
SETUP AND INSTALLATION
Connecting sources to the projector
MOLEX
MOLEX
1
10
2
3
4 5
6
8
12
13
15 9
7
11
14
16
No Item No Item No Item No Item
1. RJ-45 Cable 5. Audio In Cable 9. S/PDIF Out Cable 13. HDMI Dongle
2. HDMI Cable 6. USB Flash Drive 10. USB Power Cable 14.
Wi-Fi Dongle for Alexa
3.
RCA Component Cable
7.
Wi-Fi Dongle for
Wi-Fi Display
11. Audio Out Cable 15. RS232 Cable
4. VGA In Cable 8.
USB Cable for
Service
12. 12V DC Jack 16. Power Cord
To Next Page
