INTRODUCTION
Connections
1 643 7 108
111415 13
2 5 9
12
No Item No Item
1. RJ-45 Connector 9. Service Connector
2. RS232 Connector 10. S/PDIF Connector
3. HDMI 1 Connector 11. USB2.0 Connector
4. HDMI 2 Connector 12. AUDIO OUT Connector
5. VGA Connector 13. USB-A Connector
6. 12V OUT Connector 14. Kensington
TM
Lock Port
7. AUDIO IN Connector 15. Power Socket
8.
USB Power Out (5V 1.5A) /
USB3.0 Connector
