Page #36 background imageLoading...
Page #36 background image
English
36
USING THE PROJECTOR
Optional Filter Installed
Set the warning message setting.
Yes: Display warning message after 500 hours of use.
Note: “Filter Usage Hours / Filter Reminder / Filter Reset” will only appear when “Optional Filter
Installed” is “Yes”.
No: Turn off warning message.
Filter Reminder
Choose this function to show or hide the warning message when the changing lter message is displayed. The
available options include 300hr, 500hr, 800hr, and 1000hr.
Filter Reset
Reset the dust lter counter after replacing or cleaning the dust lter.
Power settings menu
Direct Power On
Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied,
without pressing the “Power” key on the projector keypad or on the remote control.
Auto Power Off (min.)
Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the
projector. The projector will automatically power off when the countdown has nished (in minutes).
Sleep Timer (min.)
Congure the sleep timer.
Sleep Timer (min.): Sets the countdown timer interval. The countdown timer will start, with or without
a signal being sent to the projector. The projector will automatically power off when the countdown has
nished (in minutes).
Note: The Sleep Timer is reset every time when the projector is powered off.
Always On: Check to set the sleep timer always on.
Security menu
Security
Enable this function to prompt for a password before using the projector.
Off: Choose “Off” to be able to switch on the projector without password verication.
On: Choose “On” to use security verication when the turning on the projector.
Security Timer
Can be select the time (Month/Day/Hour) function to set the number of hours the projector can be used. Once this
time has elapsed you will be requested to enter your password again.
Change Password
Use to set or modify the password that is prompted when turning the projector on.
Test pattern menu
Select the test pattern from green grid, magenta grid, white grid, white, or disable this function (off).

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Optoma UHD42 and is the answer not in the manual?

Optoma UHD42 Specifications

General IconGeneral
Native aspect ratio16:9
Projection distance1.2 - 8.1 m
Vertical scan range24 - 120 Hz
Horizontal scan range31 - 135 kHz
Projection technologyDLP
Supported aspect ratios4:3, 16:9
Contrast ratio (typical)500000:1
Screen size compatibility34.1 - 302.4 \
Projector native resolution2160p (3840x2160)
Keystone correction, vertical-40 - 40 °
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)10000 h
Focus-
Offset105 %
Throw ratio1.21:1 - 1.59:1
Zoom capabilityYes
Focal length range12.81 - 16.74 mm
Vertical lens shift range0 - 10 %
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1360 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1600 (WQXGA)
DVI portNo
HDMI version1.4a/2.0
HDMI connector typeFull-size
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in0
Noise level26 dB
Number of OSD languages10
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS
RMS rated power10 W
PlacementDesktop
Product typeStandard throw projector
Product colorWhite
Market positioningGaming
Cable lock slot typeKensington
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (max)305 W
Power consumption (standby)0.5 W
Power consumption (economy mode)220 W
Operating altitude0 - 3000 m
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 85 %
Remote control typeIR
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Depth270 mm
Width315 mm
Height118 mm
Weight3900 g
