Optoma UHD50 User Manual

English
37
USING THE PROJECTOR
When the keypad lock function is “On”, the Keypad will be locked. However, the projector can be operated by the
remote control. By selecting “Off”, you will be able to reuse the Keypad.
Information Hide
Enable this function to hide the information message.
 O󰀨: Choose “Off” to show the “searching” message.
 On: Choose “On” to hide the info message.
Logo
Use this function to set the desired startup screen. If changes are made, they will take effect the next time the
projector is powered on.
 Default: The default startup screen.
 Neutral: Logo is not displayed on startup screen.
Background Color
Use this function to display a blue, red, green, gray color, or none when no signal is available.
HDMI 1 EQ
Set the HDMI port EQ value for HDMI1.
HDMI 2 EQ
Set the HDMI port EQ value for HDMI2/MHL.
Note:
 HDMI EQ analyses the signal data and eliminates distortion due to signal loss when using long HDMI
cables. The HDMI receiver also includes a timing adjustment circuit that removes timing jitter, restoring
the HDMI signal to optimal transmission levels.
 3840x2160@60Hz suggests using the HDMI cable under 5 meters.
 3840x2160@30Hz/25Hz/24Hz suggests using the HDMI cable under 15 meters.
Reset menu
Reset OSD
Return the factory default settings for OSD menu settings.
Reset to Default
Return the factory default settings for all settings.

Optoma UHD50 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.8 - 10.6 m
Vertical scan range	24 - 120 Hz
Horizontal scan range	31000 - 135000 kHz
Projection technology	DMD
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	500000:1
Screen size compatibility	34.1 - 302.4 \
Projector native resolution	2160p (3840x2160)
Keystone correction, vertical	-40 - 40 °
Lamp power	240 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	10000 h
Focus	Manual
Offset	100 %
Focal length range	20.91 - 32.62 mm
Aperture range (F-F)	2.5 - 3.2
Full HD	Yes
Supported video modes	480i, 480p, 720p, 1080i, 1080p, 2160p
Analog signal format system	-
Supported graphics resolutions	640 x 480 (VGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 2160
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Noise level	28 dB
Noise level (economic mode)	25 dB
Card reader integrated	No
Sustainability certificates	RoHS
RMS rated power	10 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	348 W
Power consumption (standby)	- W
Power consumption (typical)	317 W
Power consumption (economy mode)	259 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Remote control type	IR

Weight and Dimensions

Depth	129.5 mm
Width	391.1 mm
Height	281.9 mm
Weight	5330 g
