Optoma UHD55 User Manual

English
44
USING THE PROJECTOR
Level 1 Level 2 Level 3 Level 4 Value
Network
Wireless Other Options
Connect via WPS
Connect via WPS (Enter
PIN)
Add New Network
[Pop up dialog]
Title: Enter the name for Wi-Fi
network
Input: (Input text)
Button: “Cancel”/ “OK”
[Pop up dialog]
Content: Type of security
Button: None, WEP, WPA/WPA2
PSK, 802.1xEAP
Portable Hotspot
Portable
Wi-Fi
Hotspot
O󰀨
On
Network
name
[Pop up dialog]
Title: Rename network
Input: (Input text)
Button: “Cancel”/”OK”
Security
[Pop up dialog]
Title: Type of security
Button: None, WPA2
PSK
Password
[Pop up dialog]
Title: Change password
Input: (Input text)
Description: The
password must have at
least 8 characters.
Checkbox: Show
password
Button: “Cancel”/”OK”
Ethernet
Status (read only)
MAC Address (read only)
Proxy Settings
None
Manual
Proxy hostname
Port
bypass proxy domains
IP Settings
DHCP
Static
IP address
Gateway
Network Prex Length
DNS1
DNS2
Reset

Optoma UHD55 Specifications

General

Native aspect ratio	16:9
Vertical scan range	24 - 120 Hz
Projection technology	DLP
Contrast ratio (typical)	1200000:1
Screen size compatibility	34.1 - 302.4 \
Projector native resolution	2160p (3840x2160)
Light source type	Lamp
Light source brightness	3600 lm
Service life of light source	15000 h
Throw ratio	1.21 – 1.59:1, ±3%
Zoom capability	Yes
Focal length range	12.81 - 16.74 mm
Aperture range (F-F)	1.94 - 2.23
DVI port	No
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	3
RMS rated power	10 W
Noise level	26 dB
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	- W
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	270 mm
Width	315 mm
Height	118 mm
Weight	3720 g
