Optoma UHD55 User Manual

English
69
ADDITIONAL INFORMATION
IR remote codes
Enter
Key
Key
num
MTX. Format Data0 Data1 Data2 Data3 Description
Power
on / o󰀨
K12 04 F1 32 CD 71 8E
Refer to the “Powering on / o󰀨 the projector”
on page 19.
Source K3 11 F1 32 CD 18 E7
Press to select an input signal.
Home K13 03 F1 32 CD 92 6D
Press to return to the Home screen.
Menu K8 17 F1 32 CD 0E F1
Press to launch the on-screen display
(OSD) menu. To exit OSD, press again.
Return K4 10 F1 32 CD 86 79
Press to return to the previous page.
Up K7 18 F2 32 CD 11 EE
Use to select items or make
adjustments to your selection.
Left K14 02 F2 32 CD 10 EF
Right K5 09 F2 32 CD 12 ED
Down K2 19 F2 32 CD 14 EB
Enter K9 16 F1 32 CD 0F F0 Conrm your item selection.
Mute K15 01 F1 32 CD 52 AD
Press to turn o󰀨/on the projector built-in
speaker.
Display
Mode
K10 15 F1 32 CD 91 6E
Press to display the Display Mode menu.
To exit the Display Mode menu, press
again.
Option K6 08 F1 32 CD 25 DA
Press to congure the Smart TV settings.
Volume - K11 12 F2 32 CD 0C F3
Press to decrease the volume.
Volume + K1 05 F2 32 CD 09 F6
Press to increase the volume.

Optoma UHD55 Specifications

General

Native aspect ratio	16:9
Vertical scan range	24 - 120 Hz
Projection technology	DLP
Contrast ratio (typical)	1200000:1
Screen size compatibility	34.1 - 302.4 \
Projector native resolution	2160p (3840x2160)
Light source type	Lamp
Light source brightness	3600 lm
Service life of light source	15000 h
Throw ratio	1.21 – 1.59:1, ±3%
Zoom capability	Yes
Focal length range	12.81 - 16.74 mm
Aperture range (F-F)	1.94 - 2.23
DVI port	No
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	3
RMS rated power	10 W
Noise level	26 dB
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	- W
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	270 mm
Width	315 mm
Height	118 mm
Weight	3720 g
