Troubleshooting
If you experience a problem with your projector, please refer to the following information. If a problem persists,
please contact your local reseller or service center.
Image problems
No image appears on-screen
 Ensure all the cables and power connections are correctly and securely connected as described in the
"Installation" section.
 Ensure the pins of connectors are not crooked or broken.
 Check if the projection lamp has been securely installed. Please refer to the "Replacing the Lamp"
section on pages 45-46.
 Ensure that the "Mute" feature is not turned on.
Image is out of focus
 Adjust the Focus Ring on the projector lens. Please see page 16.
 Make sure the projection screen is between the required distance from the projector. (Please refer to
pages 50-51).
The image is stretched when displaying 16:9 DVD title
 When you play anamorphic DVD or 16:9 DVD, the projector will show the best image in 16: 9 format
on projector side.
 If you play the LBX format DVD title, please change the format as LBX in projector OSD.
 If you play 4:3 format DVD title, please change the format as 4:3 in projector OSD.
 Please setup the display format as 16:9 (wide) aspect ratio type on your DVD player.
Image is too small or too large
 Adjust the zoom lever on the top of the projector.
 Move the projector closer to or further from the screen.
 Press "Menu" on the projector panel, go to "Display-->Aspect Ratio". Try the different settings.
Image has slanted sides:
 If possible, reposition the projector so that it is centered on the screen and below the bottom of the
screen.
Image is reversed
 Select "Setup-->Projection" from the OSD and adjust the projection direction.

Optoma UHD65 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	1.3 - 9.3 m
Vertical scan range	24 - 120 Hz
Horizontal scan range	31 - 135 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (dynamic)	1200000:1
Contrast ratio (typical)	-
Screen size compatibility	26.45 - 302.2 \
Projector native resolution	2160p (3840x2160)
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	10000 h
Focus	Manual
Throw ratio	1.39 - 2.22:1
Zoom capability	Yes
Focal length range	20.91 - 32.62 mm
Aperture range (F-F)	2.5 - 3.26
Vertical lens shift range	-15 - 15 %
DVI port	No
MHL version	2.1
HDMI version	1.4a/2.0
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	0
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Cable lock slot type	Kensington
Noise level	- dB
Noise level (economic mode)	25 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, POR, RUS
RMS rated power	8 W
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Power source	AC
AC input voltage	110 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	305 W
Power consumption (economy mode)	249 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	331 mm
Width	498 mm
Height	141 mm
Weight	7800 g
