Electrical Installation 51-
The Xi 80/410 provides the following direct inputs and outputs:
Name
Description
max range / status
AI
or
DI
Analog input
0-10 V
1)
Digital input
(active-low = 0…0,6 V)
24 V
AO
Analog output
Alarm output
0/4-20 mA
0/4-20 mA
1)
The AI is designed for max. 24 V, the voltage level above 10 V is not interpreted
In addition to the above direct in- and outputs, the Xi 80/410 has an RS485 interface. This interface can be
used to control the external industrial PIF.
