optris Xi 400 User Manual

Electrical Installation 61-
Figure 30: Connection of 3 industrial PIFs via RS485
Each stackable industrial PIF must have its own RS485 address. The address must be set
directly on the board. For the PIF which is the furthest away the 120R switch (TERM. –
Termination) has to be set.
