Figure 7-3 Removing the Bridge Battery Cover
4. Carefully remove the battery from the compartment until you can access the
connector cable. Use your fingers or a gripping tool to carefully separate the
connector. Make sure you hold and pull the plastic connectors and not the wires.
After disconnecting the battery, set it aside.
Figure 7-4 Battery Connector Cable
5. Connect the replacement battery. Tuck the excess battery wire into the casework
and place the battery in the battery compartment.
Chapter 7
Replacing the Bridge Battery in the MICROS Tablet 720
7-6
