Replacing the Bridge Battery in the MICROS Tablet 720
Follow the steps below to replace the bridge battery in the MICROS Tablet 720.
Prerequisites
• #1 Phillips head screwdriver
• Tweezer or needle nose pliers
Procedure
1. Place the tablet face down on a rubberized or cloth surface to prevent scratches.
2. Slide the battery release latch until the main battery detaches from the tablet body.
Set the main battery aside.
Figure 7-2 Removing the MICROS Tablet 720 Main Battery
3.
Remove the bridge battery cover using a #1 Phillips screwdriver. For some tablets,
you may need to peel back the license decal first.
Chapter 7
Replacing the Bridge Battery in the MICROS Tablet 720
7-5
