Table 1-4 Input/Output Port on the Oracle MICROS Tablet 720
Feature Description
A. Barcode Scanner (Optional) Captures and reads information contained in a
bar code.
B. Magnetic Stripe Reader (MSR) Reads the information encoded in the
magnetic stripe of payment cards.
C. Headphone Jack Use to connect a headphone, a microphone,
or a headset.
D. USB 2.0 Port Use to connect peripherals such as storage
devices, printers, and displays.
E. 5V DC Power Input Use to connect a power adapter to provide
power to your tablet and charge the battery.
Table 1-5 Button Functions on the Oracle MICROS Tablet 720
Feature Description
1. Power Button Turns the tablet on or off.
2. Scanner Trigger Use to activate the barcode scanner.
3. Battery/Power LED Indicates the power and battery status.
Battery LED Status has more information on
the behavior of the LED.
4. Battery Latch Use to unlock and remove the battery.
5. Battery Sensor Senses the presence of a battery. Located in
the battery compartment under the battery.
Inadvertently pressing this when the battery is
removed disables the “hot swap” capability
and causes the tablet to power off.
Technical Specifications
The following tables contains the technical specifications for the Oracle MICROS
Tablet 720, Oracle MICROS Tablet 721, and Oracle MICROS Tablet 721P.
Table 1-6 Technical Specifications for the Oracle MICROS Tablet 720
Feature MICROS Tablet 720
Processor Intel Atom Quad Core, 1.33GHz
RAM 2GB
Storage 64GB Flash
Operating System Microsoft Windows Embedded 8.1 Industry
Pro
Microsoft Windows 10 IoT Enterprise 2016
LTSB
Display 7-inch LED-Backlight Screen with Capacitive
Touch
Chapter 1
Technical Specifications
1-6
