TECHNICAL MANUAL BLUE PAPER GAIN · HYDRO 202148 | ORBEA ORBEA | 49
EN
OC1 ROAD COMPLETE STEMS
24 OC1 ROAD STEM 80mm
ART Nº: X0718000 QTY.
24.1 OC1 ROAD STEM 80mm
1
24.2 LOGO ORBEA FACEPLATE
1
26 OC1 ROAD STEM 100mm
ART Nº: X0710000 QTY.
26.1 OC1 ROAD STEM 100mm
1
26.2 LOGO ORBEA FACEPLATE
1
28 OC1 ROAD STEM 120mm
ART Nº: X0712000 QTY.
26.1 POC1 ROAD STEM 120mm
1
26.2 LOGO ORBEA FACEPLATE
1
25 OC1 ROAD STEM 90mm
ART Nº: X0719000 QTY.
25.1 OC1 ROAD STEM 90mm
1
25.2 LOGO ORBEA FACEPLATE
1
27 OC1 ROAD STEM 110mm
ART Nº: X0711000 QTY.
24.1 OC1 ROAD STEM 110mm
1
24.2 LOGO ORBEA FACEPLATE
1
2
4
6 N.m
GREASE
4
6 N.m
GREASE
6JG 1% UVGO WUGU C RTQƂNGF VQRECR CPF
countersunk bolt that are not included
with the complete stem kits. They are both
included in the OC1 stem hardware kit. The
internal cabling headset spacers may change
depending on what frame the OC1 stem is
assembled.
HANDLEBARS
Check the geometry and characteristics of the OC road
handlebars range on the OC Road Cockpit components
manual on the Support section of our website.
www.orbea.com/es-es/soporte/manuales/
