Orbea ORCA M20 User Manual

TECHNICAL MANUAL BLUE PAPER ORCA · OMR 20212 | ORBEA ORBEA | 3
EN
INDEX
01 INTRODUCTION 4
Key to symbols
02 ORBEA WARRANTY 6
03 MAINTENANCE 8
Maintenance schedule
Spare parts
After a crash or an impact
04 WARNINGS OF USE 12
Maximum tyre width
Minimum seatpost insertion
Maximum number of headset spacers
Headset spacers on above the stem
Intended use
05 ORCA OMR 2021 14
Geometry and sizing
6GEJPKECNURGEKƂECVKQPU
Assembly and spare parts
Headset
Axles and rear derailleur
Frame hardware
Cabling
Stems
Cutting the fork steerer tube
06 HANDLEBARS 42
07 POWERBOX POWERMETER 43
08 DECLARATION OF CONFORMITY 44
09 ADDITIONAL INFORMATION 45
EN P.03 | ES P.46

Orbea ORCA M20 Specifications

General

Seatpost	Orbea OC2 Carbon
Frame Material	Carbon
Fork	Orbea Carbon Fork
Handlebar	Orbea OC2 Road, 31.8mm
Stem	OC2
Wheels	Vision Team 30 Disc
Saddle	Prologo Kappa
