1. Preparation
1.1 Clear a 2 meters time 2.5 meters working space before unpacking your Elliptical Cross Trainer.
1.2 The assembly steps required two persons.
2. Open carton
2.1 Use a sharp knife, open the carton and lay it flat on the floor.
2.2 Remove all loose components.
2.3 Refer to the checklist and check that everything is present.
NOTE:
To protect the Elliptical Cross Trainer while assembling we suggest that you do not remove the protective
packing material until it is absolutely necessary.
3. Remove Rear Protection Tube
3.1 Lift the rear of the machine off the floor and slide a polystyrene block under the rear of the machine.
3.2 Remove Two Bolts [B11], Two Washers [B10] and remove the Protection Tube.
[Remove bolts with the Hex Tool with Phillips Screw Driver provided.]
To Next Page
