TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 5 of 10

3 Replacing the ADMx

3.1 Removing the ADMx

Step 1

Using an 8mm Open/ring

wrench, disconnect the

described RF cable from the

ADMX.

Step 2

Unlock and remove the

network cable.

Step 3

Using an 8mm Open/ring

wrench, disconnect the two

described RF cable from the

ADMX.
