TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 2 of 10
1.3 ADMx Description
The ADMX (mounted on the PEDESTAL) and the BDMX (inside the BDE CCU) multiplexer
modules form the communications link between the ADE and BDE, minimizing the physical
connection to a single coaxial cable (LMR-200, LMR-400 or LMR-600, depending on the
required cable length).
The ADMX also provides integral amplification and attenuation of the Tx and Rx paths.
Figure 1-1: ADMx
1.4 Spare Kit Contents
The following table provides a list of the parts in the ADMX spare kit.
Table 1-2: Spare Part Kit Contents
ADMX - FOR AL-7103/7107-SYS
