B49 Water Bottle Holder 2
B50 Handlebar 2
C. Electric and Drive Parts
No. Description Qty No. Description Qty
C2 Running Belt 1 C20 Magnetic Ring 2
C3 Rear Roller 1 C23 Overload Protector 1
C4 Front Roller 1 C27 Long Single Cord (Blue) 1
C5 Running Deck 1 C31 Short Single Cord (Blown) 2
C6 Cylinder 1 C32 Short Single Cord (Blue) 1
C7 Drive Belt 1 C33 Single Ground Wire 1
C8 Power Switch 1 C34 Outlet 1
C9 Controller 1 C42 Brushless Motor 1
C12 Incline Motor 1 C43 LeftQuick Wheel Button 1
C13 Safety Key 1 C44 Right Quick Wheel Button 1
C14 Long Single Cord (Brown) 1 C50 Magnetic Ring (Large) 1
C15 Power Cable 1 C56 Magnet 1
C16 Console Upper Cable 1 C59 Sensor 1
C17 Console Lower Cable 1
D. Hardware Parts
No. Description Qty No. Description Qty
D1 Open End Wrench 13-15-17 1 D105
Button Head Cap Screw,
M10X20mm
8
D2 Allen Wrench 6mm 1 D111 Spring Washer M10 2
D3 Allen Wrench 5mm 1 D114
Button Head Cap Screw,
M8X65mm
2
D7
Button Head Cap Screw,
M10X60mm
1 D145
Phillips Pan Head Screw,
M5X16mm
18
D10
Button Head Cap Screw,
M10X45mm
3 D146
Socket Head Cap Screw,
M10X60mm
2
D13
Button Head Cap Screw,
M8X15mm
4 D160
Socket Head Cap Screw,
M8X30mm
6
D14
Button Head Cap Screw,
M8X30mm
1 D165
Socket Head Cap Screw,
M6X35mm
4
D15
Button Head Cap Screw,
M8X40mm
2 D167
Socket Head Cap Screw,
M10X50mm
2
D16
Button Head Cap Screw,
M8X45mm
1 D172 Allen Wrench 8mm 1
