Orbit StarTrack ST36T - Parts List

PARTS LIST
A. Welding Parts
No.
Description
Qty
No.
Description
Qty
A1 Main Frame 1 A64 Countersunk Washer 4
A2 Base Frame 1 A67 Compression Sleeve 2
A3L Left Upright 1 A79 Safety Key Pin
1
A3R Right Upright 1 A81 PU Support Bracket
2
A4 Handlebar 1 A82 Adjustment Wheel Bracket
2
A5 Incline Bracket 1
A13 Belt Guide 2
A59
Long Solid Side Rail Fixing
Plate
4
A60
Short Solid Side Rail Fixing
Plate
2
A62 Incline Axle Screw 2
B. Plastic Parts
No. Description Qty No. Description Qty
B1 Console Monitor 1 B52 Solid Side Rail 2
B1-1 Overlay 1 B69L Left Rubber Ring 1
B1-2 MembraneKey 1 B69R Right Rubber Ring 1
B1-5 Tablet Holder 1 B89 Large Incline Bearing 4
B2 Console Cover 1 B105 Arc Shaped Foot Pad 2
B7 Transport Wheel 2 B116 Small Incline Bearing 4
B10 Cushioning Stopper 2 B118 Rubber Cushion 4
B11L
Left Side Cover
1 B119 Short Deck Cushion 2
B11R
Right Side Cover
1 B120 Long Deck Cushion 2
B13 Upper Motor Cover 1 B125 Adjustment Wheel Cover 2
B14 Bottom Motor Cover 1 B142 Transport Wheel (45mm) 2
B15 Upper Side Rail 2 B168 Anti-slippery Pad 1
B16L Left End Cap 1
B16R Right End Cap 1
B17 Adjustment Wheel 2
B20 WirePlug 1
B21 SquarePlug 2
B34 EVA Pad 1
33
