Operation Manual
"Open Frame Welding Head OSW Series"
2
Table of contents
Page
Table of contents 2
1. General 3
2. Safety information 4
3. Application ranges - dimensions - views 5
4. Functional principles of the open frame weld head 9
5. Connecting the weld head to the power supply 10
6. Operation of the open frame weld head 12
7. Spare parts and consumables 15
7.1. Torch parts list 15
7.2. Torch arm parts list 15
8. Predetermined breaking point in drive 16
8.1. Maintenance 16
9. Addendum 17
9.1. Water-cooled torch 17
9.2. Fillet welds 18
9.3. Torch variants 18
10. Addendum OSW new version Bj 19
