Orbitsound M10LX - Getting Started; Connect, Power On, and Switch On

5
Getting Started
Connect, power on
1
Connect power
2
Connect Subwoofer
3
3
Switch on
Connect Power
Spatial soundbar with subwoofer and Bluetooth
Subwoofer Output
4 ohm minimum
Only connect supplied subwoofer
©2013 Orbitsound Ltd. Model: M10LX
1
1
2
2
2
1. Connect the subwoofer as shown (see below picture)
2. Connect power to the soundbar.
3. Switch on the power switch.
