Orca 40 CL - Page 59

59
ENTRETIEN
Angolo delle
ruote
Percorso
Angolo delle
ruote
Percorso
Configurazione 2: B-C, quando l’angolo di curvatura è eccessivo
Configurazione 3: C-C, quando la piscina è particolarmente lunga e larga
ISTRUZIONI D’USO
10
Setting 3: C-C, when the length and width of the swimming pool are large
Wheel Angle
Running route
10
Setting 3: C-C, when the length and width of the swimming pool are large
Wheel Angle
Running route
8
Then re-install the limit pile into chassis to realize the different running paths.
b. Four settings for wheels are recommended:
Setting 1: default setting: B-C, for most of pools
Wheel Angle
Running path
9
Setting 2: C-A, when the turning angle is too large
Wheel
Angle
Running
path
