8
Position
Table a curve
speed
DIP switch position
Air output
Pressure
Power
consumption
Setting Qv Pf Pe
(Number) 1 2 3 4 5 6 7 [m
3
/h] [Pa] [W]
Absent 0 - - - - - - - 45 5 2
*Low 1a Off - - - - - Off 70 10 3
Low 2a On - - - - - Off 85 14 4
*Medium 3a - Off Off Off - - Off 150 46 7
Medium 4a - On Off Off - - Off 171 62 9
Medium 5a - Off On Off - - Off 197 81 12
Medium 6a - On On Off - - Off 222 101 15
Medium 7a - Off Off On - - Off 245 123 20
Medium 8a - On Off On - - Off 270 150 27
Medium 9a - Off On On - - Off 293 175 32
Medium 10a - On On On - - Off 316 205 38
*High 11a - - - - Off Off Off 245 123 20
High 12a - - - - On Off Off 295 177 33
High 13a - - - - Off On Off 318 208 40
High 14a - - - - On On Off 342 241 50
Table A - Table A or B is selected by setting DIP switch 7 to on or off.
