OREC FL 500 - Table of Contents; Contents; Caracteristics; Check List

OREC FL500A - © SAT 03/03
3
CONTENTS
INTRODUCTION ............................................................................................................................. 2
CONTENTS .................................................................................................................................... 3
CARACTERISTICS ......................................................................................................................... 3
CHECK LIST ................................................................................................................................... 3
SAFETY RULES ............................................................................................................................. 4
DESCRIPTION OF THE MACHINE................................................................................................. 6
SAFETY STICKERS ....................................................................................................................... 7
CONTROLS .................................................................................................................................... 8
OPERATION ................................................................................................................................... 9
MAINTENANCE OPERATIONS TO BE CARRIED OUT BY THE USER....................................... 11
BREAKDOWNS AND SOLUTIONS .............................................................................................. 17
TIGHTENING TORQUES (Nm) ..................................................................................................... 17
EC CONFORMITY DECLARATION .............................................................................................. 18
MEASUREMENT OF VIBRATIONS .............................................................................................. 18
EC CONFORMITY DECLARATION .............................................................................................. 19
MEASUREMENT OF VIBRATIONS .............................................................................................. 19
LIMITED WARRANTY ................................................................................................................... 20
NOTES .......................................................................................................................................... 20
CARACTERISTICS
Model
FL500BC
FL500BC-Hi
Engine
HONDA GXV160
HONDA GXV160
Transmission
Belts
Belts
Forward speed (km/h)
(1) 1,5 (2) 2,5 (3) 4.0
(1) 1,5 (2) 2,5 (3) 4.0
Reverse speed (km/h)
1,7
1,7
Cutting width (mm)
500
500
Height of cut (mm)
20-80
20-80
Weight (kg)
68
68
Fuel tank capacity (liters)
1.4
1.4
Blade transmission
Belt
Belt
blade speed (rpm)
2268
2968
Over all width (mm)
580
580
CHECK LIST
INSTRUCTIONS TO THE DEALER
• The assembling, the installation and the first application of the machine is under the OREC dealer’s
responsability.
• Read the instruction manual as well as the safety measures. Check that all the before delivery and
at delivery check points specified in the following lists have been verified and possibly modified
before delivering the machine to its owner.
