SPECIFICATIONS
Model
HRC663 HRC673 HRC813
Engine
HONDA GX270 HONDA GX270 HONDA GX340
Engine power(HP)
8.45Hp 8.45Hp 10.7Hp
Transmission
Mechanical Mechanical Mechanical
Forward speed(km/h)
(1) 0.95, (2) 1.99, (3) 3.50 (1) 0.95, (2) 1.99, (3) 3.50 (1) 0.95, (2) 1.99, (3) 3.50
Reverse speed(km/h)
0.95 0.95 0.95
Cutting width (mm)
650 650 800
Height of cut (mm)
50 to 110 50 to 110 50 to 110
Weight (kg)
170 170 190
Fuel tank(liters)
5.3 4.1 4.7
Blade transmission
belts belts belts
Blade engagement
belt tension belt tension belt tension
blade speed (rpm)
3075 3075 3075
Over all width (mm)
810 810 940
