Oreck XL21-700ECC

Part Numbers Listing: XL21-600ECC, XL21-600ECB, XL21-700ECC, XL21-700ECB, XL21-700ECP, XL21-700ECT,
Type 1-4 Units
# Item Order # Qty. Pk.
1 XL21-600ECC: Handle Assy, includes items #56, 57, 58, 59, 09-77093-52 1 1 NLA NLA NLA
60, 61, 63, 64 Type 1 Units Only - Order Assembly 1a
XL21-600ECB: Handle Assy, includes items #56, 57, 58, 59, 09-77093-51 1 1 NLA NLA NLA
60, 61, 63, 64
Type 1 Units Only - Order Assembly 1a
1a Kit, Retro, Handle Assembly, Black, includes items #57, 58, 09-77207-01 1 1
59, 62, 63
Type 1 Units Only
2 Bag Dock, Rear, Type CC (Use w/#3 or order #83) 75583-03-0000 1 1
3 Bag Dock Hinge, Type CC (Use w/#2 or order #83) 75582-03-0000 1 1
4 Dust Bag, (8 Pk.) Hypo Allergenic CCPK8DW 1 8
Dust Bag, (25 Pk.) Hypo Allergenic CCPK25DW 1 25
Dust Bag, (8 Pk.) Odor Control CCPK8OF 1 8
Dust Bag, (25 Pk.) Odor Control CCPK25OF 1 25
5 XL21-600ECC / XL21-600ECB / XL21-700ECC / XL21-700ECB 77039-06 1 1
Outer Bag, Tan, Black, HEPA, Hypo, Anti-Microbial
XL21-700ECP: Outer Bag, Tan, Black, Pink Ribbon 77039-07 1 1
XL21-700ECT: Outer Bag, Gray, Black, Silver 77039-08 1 1
6 XL21-600ECC / XL21-700ECC: Bag Clip, Front, Creme 09-77094-02 1 1
XL21-600ECB / XL21-700ECB / XL21-700ECP: Bag Clip, 09-77094-01 1 1
Front, Black
XL21-700ECT: Bag, Clip, Front, Black w/Silver 09-77094-04 1 1
7 XL21-600ECC / XL21-700ECC: Bag Clip, Rear, Creme 77006-01-453 1 1
XL21-600ECB / XL21-700ECB / XL21-700ECP / XL21-700ECT: 77006-01-0327
Bag Clip, Rear, Black 1 1
8 Clamp, Bag Clip 77003-01-0327 1 1
9 Bag Spring 75015-01 1 1
10 Connector Assembly Types 1-3 order #61b also 77075-03-0327 1 1
11 Handle, Carry, Rear, Gray 77014-01-0384 1 1
12 Clamp, Carrying Handle 77015-01-0327 1 1
13 Detent, Carrying Handle 77066-01 1 1
14 Collar, Upper Handle 77048-01-0384 1 1
15 Tube, Lower
Type 1 & 2 Units Only
77002-02 1 1
Tube, Lower
Type 3 & 4 Units Only
77002-03 1 1
16 Label, Tube 77078-02 1 1
17 Collar, Lower 77049-01-0384 2 1
18 O’Ring, Tube Connector 77054-01 2 1
19 Fan Housing 77025-01-0327 1 1 NLA NLA NLA
20 Fan Housing Cover/ Seal Overmold 77024-02-0327 1 1 NLA NLA NLA
21 Fan Kit w/Washers (See pg. 2) 09-77230-51 1 1
22 Clamp, Scroll 77056-01 2 1
23 XL21-600ECC / XL21-700ECC: Headlight Cover Assembly, 09-77095-04 1 1
Creme
XL21-600ECB / XL21-700ECB / XL21-700ECP: Headlight 09-77095-03 1 1
Cover Assembly, Black
XL21-700ECT: Headlight Cover Assembly, Chrome 09-77095-07 1 1
24 Light Lens, Front 77035-01-455 1 1
25 Bulb (Non LED Units Only) 77051-01 2 1
26 XL21-600ECC / XL21-700ECC: Top Cover Assembly 09-77101-05 1 1
w/ Side Lens, Creme
XL21-600ECB / XL21-700ECB / XL21-700ECP: Top Cover 09-77101-07 1 1
Assembly w/ Side Lens, Black
XL21-700ECT: Top Cover Assembly w/ Side Lens, Lt. Gray 09-77101-10 1 1
