Orei BK-104 - Specifications

Page
06
Specications
Technical
HDMI Compliance HDMI 2.1
HDCP Compliance HDCP 2.3
Video Bandwidth 48Gbps
Video Resolution Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit
Color Space RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0
Color Depth 8/10/12-bit
HDR HDR, HDR10, HDR10+, Dolby Vision, HLG
Audio Formats
HDMI Input/Output:
LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
ESD Protection
Human body model — ±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Connection
Input 1 × HDMI IN [Type A, 19-pin female]
Output 4 × HDMI OUT [Type A, 19-pin female]
Control 1 × SERVICE [USB Type C, Update port]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 145mm[L] × 68mm[W] × 17mm[H]
Weight 263g / 9.27oz
Power Supply
Input: AC 100-240V 50/60Hz, Output: DC 5V/2A
(US/EU standards, CE/FCC/UL certified)
