13
Understanding the optional NuVinci 360 Continuously Variable
Transmission
Changing gears with your N360 hub is as simple as rotating the shifter grip. The
graphic display shows a hill for slower speeds and a flat line for faster speeds. Please note
that the display is inverted on the ELF. For more detailed information on the NuVinci N360,
visit: www.fallbrooktech.com/cycling/n360
Shifting to Higher Gears
Shifting to a higher or faster gear increases the resistance and makes the ELF harder to
pedal (good for cruising on flat ground or downhill). Shift to a higher gear by rotating the
shifter grip away from you while pedaling. You may notice that it is harder to pedal at low
speeds and on hills when in a higher gear. The line on the shifter display will show a flatter
line (like flat ground).
Down Shifting
Shifting to a lower or slower gear makes the ELF easier to pedal, so it is great for
starting out or climbing hills. Down shift by rotating the shifter grip toward you while
pedaling. The line on the shifter display will show a more curved line (like a hill).
Using the CycleAnalyst
®
(If Equipped)
The CycleAnalyst® is an advanced bicycle computer that can help you track your
speed, mileage, battery level and energy consumption.
Basic Button Navigation
• Press right/left buttons to navigate Status or Setup Screens.
• Press/hold left button to enter Setup.
• Press/hold right button to reset trip statistics.
• From the 'Trip Regen Stats' status screen, press/hold right button to reset peak
trip statistics.
Status Screens
There are eleven Status screens which display information grouped by function. Some
information (e.g. speed, Amps) is displayed on more than one screen to give the operator
a more comprehensive view without changing screens. Due to the design of the ELF,
screens 3 and 5 do not apply and should be ignored. The status screens are shown below
and can be navigated through by pressing the left or right buttons on the CycleAnalyst
®
.
