16
Understanding Your Battery
The 11Ah battery pack and the 15 Ah battery pack both come in the plastic case
shown below. Each battery pack is made of Li-ion NMC batteries and has a built-in Battery
Management System (BMS).
Battery Connections
In order to power the ELF and allow the solar panel to charge the battery, you must
plug the black plug located on the ELF into the corresponding plug on the battery. Do so
by grabbing both terminals at their base and pressing them firmly together until you hear a
click. The two connectors are designed to mate only one way. Be sure to secure cables
away from the chain and do not allow them to drag.
When disconnecting the main power connection, avoid
personal injury on the surrounding elements by disconnecting
the connectors using a gentle wiggle/pull motion.
