BTP-R580 USER MANUAL
- 33 -
6.5 WLAN interface
Features
Supports 802.11b、802.11g communication
Supports 9100 port print and LPR print
Supports ASB (Auto Status Back)
Supports parameter configuration
Supports firmware program upgraded online
Supports HTTP
Protocols are supported as below
IP
ARP
ICMP
TCP
UDP
DHCP
TFTP
HTTP
WLAN interface uses wireless USB network card of which the main
specification should be requested from the local distributor or
manufacture.
6.6 Signal definition of power connector
Internal signal definition of power
Pin Signal name
1 E
2 L
3 N
Table 6.6-1
